MPPT Solar Charge Controller, Electric Vehicle Voltage Regulator, 24V 36V 48V 60V 72V - High Efficiency, Real Time Display, Multi Battery Compatibility

Item Type: Solar Boost ControllerMaterial: Aluminum AlloyBattery Type: 24V, 36V, 48V, 60V, 72V Self Recognition (Default 48V)Overvoltage: 28.8V(24V), 43.2V(36V), 57.6V(48V), 72.0V(60V), 86.4V(72V), Can be set by yourself.PV Maximum Power: 600W at 18VPV Maximum Current: 33ASolar Input Voltage Range: 12-50V ( Solar panel voltage needs to be lower than battery voltage)MPPT Voltage Range: 15-45VReverse Connection Protection: Reverse battery connection will blow the .MPPT Efficiency: >99%.Efficiency of The Whole Machine: ＞95%No Load Loss: Operating Temperature: -20℃-65℃Insulation Resistance: AC1KV, 5min Test, 20MΩ Grade: IP65Package List：1 x Solar Boost Charge Controller2 x Note:1. Installation: When installing this controller, you should keep a certain distance and insulation strength between the controller and the electric vehicle motor controller and take good and damp proof measures.2. Wire: The length of the wires connecting the controller to the battery and the controller to the solar panel should be as short as possible to minimize electrical loss.3. Wiring: Connect the controller to the solar panel first, pay attention to the positive and negative poles, do not reverse. If the connection is reversed or poor , the red indicator or display does not show, you should check the connection line is not connected. When the wiring is correct, the red light or monitor voltage display. Then connect the controller and the battery, pay attention to the positive and negative poles, do not connect the reverse. When connected correctly, the blue indicator light is on, working normally.4. The solar panel should be placed outdoors, all in the sunlight. The controller has no display on cloudy days or no sunlight.

• [MpPT Technology]: Features advanced MPPT maximum power point tracking technology with up to 99% tracking efficiency to maximize solar energy harvesting and reduce panel costs.
• [High Conversion Efficiency]: Built with premium components, this controller delivers a maximum 97% conversion rate, ensuring fast and efficient power regulation for reliable solar charging.
• [Clear Real-Time Display]: Equipped with a 4-digit tube display showing panel voltage, charging current, and battery voltage, enabling easy monitoring of charging status at a glance.
• [Wide Voltage Range]: Supports a broader photovoltaic array voltage ranging from 12V to 50V with adjustable overvoltage settings for versatile application across various solar setups.
• [Versatile Battery Support]: Compatible with multiple battery types including lithium and lithium iron batteries, making it suitable for diverse energy storage needs and electric vehicle charging.
